MegaPAC L4D


Quadruple 24" HD displays in a high performance, rugged portable setup.

Download Datasheet

Video Preview

Quadruple Large Display High Performance Rugged Portable

The MegaPAC L4 is a robust computer built with four FHD displays, suitable for mission critical applications. It comes equipped with a dual system Intel core processors to provide fast, reliable, scalable high-performance computing power. This is ideal for big data analytics and geographic information systems.

Technical Specifications

Product MegaPAC L4D
Display 4x 23.8" FHD 1920x1080 IPS panel - 1000nits
CPU Intel CORE i7 9700E, 2.60 GHz/4.4Ghz in turbo, 8 cores, 12 MB cache
Memory 32GB-DDR4, 2666 MHz
Graphics Card NVIDIA Quadro P2200, Pascal GPU, 5GB-DDR5 RAM
I/O 6x USB 3.1,
4x COM ports (RS232/RS422/485),
1x Audio out, 1x mic out,
1x VGA, 1x DVI-D, 1x DisplayPort,
16 GPIO in terminal block
OS Drive M.2 1T GB SSD
Storage 2x 1TB SSD
Power Supply 750W PFC PSU, 90~264VAC, 47~63Hz input
Dimensions Height: 16.39" (416mm),
Width: 22.96" (583mm),
Depth: 11.98" (304mm)
Weight 62.8lbs (28.5kg)
Quality ISO 9001
Customization Military connectors, custom I/O, and more.

Configuration Options

The technical specifications are an example of the system's capabilities. They can be customized specifically for your needs. If you have any questions, feel free to contact one of our sales representatives.

Contact Sales

Compare Similar Systems

At a glance, it may be difficult to see the differences among some of our products. As a result, simply click the button below to see the differences among other similar systems.

Product MegaPAC L4D FlexPAC L3 MegaPAC L3
Display 4x 23.8" FHD 1920x1080 IPS panel - 1000nits Triple 17.3" or 18.5" Full HD 1920x1080 Triple 23.8" UHD 3840x2160 - 350 nits (Optional: 800 nits - 650 nits with touchscreen),
or Triple 23.8" Full HD 1920x1080 - 250 nits (Optional: 1000 nits - 800 nits with touchscreen),
or Triple 23.8" WUXGA 1920x1200 - 250 nits (Optional: 1000 nits)
CPU Intel CORE i7 9700E, 2.60 GHz/4.4Ghz in turbo, 8 cores, 12 MB cache Latest Single/Dual Intel® Xeon, Intel® Core, AMD Ryzen™, or AMD EPYC™ Latest Single/Dual Intel® Xeon, Intel® Core, AMD Ryzen™, or AMD EPYC™
Memory 32GB-DDR4, 2666 MHz Up to 1TB DDR4 RAM Up to 1TB DDR4 RAM
Graphics Card NVIDIA Quadro P2200, Pascal GPU, 5GB-DDR5 RAM Integrated HD graphic controller
or application specific graphic controller
Integrated HD graphic controller
or application-specific graphic controller
I/O 6x USB 3.1,
4x COM ports (RS232/RS422/485),
1x Audio out, 1x mic out,
1x VGA, 1x DVI-D, 1x DisplayPort,
16 GPIO in terminal block
N/A N/A
OS Drive M.2 1T GB SSD N/A N/A
Storage 2x 1TB SSD Up to 36TB (Removable Option Available) Up to 150TB (Removable Option Available)
Power Supply 750W PFC PSU, 90~264VAC, 47~63Hz input 850W 100/240VAC, 50/60Hz auto-switching 80 PLUS GOLD rated power supply 850W 100/240VAC, 50/60Hz auto-switching 80 PLUS GOLD rated
Optional: 1000W or 1200W 100/240VAC, 50/60Hz auto-switching 80 PLUS Platinum rated (with 10 year warranty)
Optional: 28VDC power supply
Dimensions Height: 16.39" (416mm),
Width: 22.96" (583mm),
Depth: 11.98" (304mm)
Folded:
Height: 14.5" (368mm)
Width: 17.125" (435mm)
Depth: 11.75" (298.5mm)

Deployed:
Height: 14.5" (368mm)
Width: 43.0" (1092mm)
Depth: 11.75" (298.5mm)
Height: 16.39" (416mm),
Width: 22.96" (583mm),
Depth: 11.98" (304mm)
Weight 62.8lbs (28.5kg) ~47 lbs (21.3kg) 52.82 lbs (24kg)
